Brand Name : QUESTT
Model Number : QA-FL1500W
Certification : CE ISO
Place of Origin : China
MOQ : 1
Payment Terms : T/T, Western Union,
Supply Ability : 3000 sets per year
Delivery Time : 7 days
Packaging Details : wooden case
Warranty : 1 Year
Wavelength : 1064nm
Laser type : fiber laser
Max. output power : 1000w 1500W
Power supply : 220v/50Hz
After-sales service provided : Engineers available to service machinery overseas
Cooling system : Air Cooled
Air cooling laser welding cleaning machine
Features


Parameters
| Model | QA-FL1000W | QA-FL1500W | QA-FL2000W |
| Average output power | 1000W | 1500W | 2000W |
| Operation Mode | CW/Modulate | ||
| Max Modulation Frequency | 5KHz | ||
| Output Power Stability | ±3% | ||
| Red Laser | Yes | ||
| Terminal Type | QBH | ||
| Beam Quality | 1.3M2 | 1.5M2 | 1.8M2 |
| Polarization | Random | ||
| Delivery Cable Length | 20M | ||
| Power Supply | 1 PH 220V five wire connect | ||
| Control Mode | RS232/AD | ||
| Power Consumption | 4KW | 5KW | 6KW |
| Cooling | Water Cooled | ||
| Operation Temperature | 10-40 degree | ||
| Max Depth of welding | 3mm | 4mm | 5mm |
| Machine Weight | 39Kg | 42Kg | 50kg |
| Package size | 1230*730*1440mm | ||
Samples
|
|
3 In 1 1000w 1500w air cooler fiber portable handheld laser welding machine Images |
